- SKU:
- FOPL-307224
- Coil Length:
- 4.25
- Title:
- E7 CD Ignition + E93 Racing Coil Ignition Kit
- Coil Width:
- 3.5
- Grade Type:
- Performance
- Coil Height:
- 3.25
- Maximum RPM:
- 12000
- Turns Ratio:
- 0.14
- Current Draw:
- 1 Amp per 1,000 RPM
- Limiter Type:
- Sequential
- Trigger Type:
- Points & Mag
- Limiter Range:
- 100-12,000
- IPU Compatible?:
- Yes
- Maximum Voltage:
- 50000
- Operating Range:
- 12,000+
- Timing Accuracy:
- 0.5
- C.A.R.B. Exempt?:
- No
- Limiter Accuracy:
- 30
- Operating Voltage:
- 10-20
- C.A.R.B. EO Number:
- N/A
- Coil Wire Included:
- No
- Ignition Box Width:
- 6.3
- Leakage Inductance:
- 6.8
- Primary Inductance:
- 1.9
- Primary Resistance:
- 0.2
- Software Included?:
- Yes
- Ignition Box Height:
- 2.2
- Ignition Box Length:
- 8.3
- Rev Limiter Included:
- Yes
- Secondary Resistance:
- 0.82
- Timing Retard Stages:
- 1
- Limiter RPM Increment:
- 100
- Primary Energy Output:
- 160
- Peak Spark Gap Current:
- 510
- Primary Voltage Output:
- 450
- Hall-Effect Compatible?:
- Only compatible with aftermarket crank trigger pickup
- Mounting Tray Included?:
- No
- Minimum Operating Voltage:
- 10
- Mounting Hardware Included:
- Yes
- Instruction Manual Included:
- Yes
- Multi-Strike Duration (Crankshaft Rotation):
- 20
- AAIA SKU:
- 307224-DXKP
- Manufacture Code:
- 307224
- Part Types:
- PROGRAMMERS & TUNERS, Ignition Kit
